Dental Digital Intraoral X Ray Sensor Dental X Ray Machine Image
System HDR 500 Sensor
Product instruction:
Dental digital x-ray imaging system is consisted of sensor, image
controller, image capture system and connection cable (USB port) ,
connected with PC or notebook via USB cable. The power of
controller and sensor is supplied by USB port, require no battery
or power charge system. The whole equipment need to work together
with imaging software.
The sensor active surface is flat including the size 1 and size 2.
u Size1, universal sensor---Use for regular procedures, both for
children and adult .
u Size2 sensor---Use for bitewings procedures.
Feature of x ray sensor dental digital:
1.Multi-languages with 10 types.
2.Operation system: desk top & laptop (Windows 2000, XP, Win 7, Win
8,Win 10)
3.Twain driver: our RVG compatible with KODAK, SIRONA, SCHIC, etc.
4.Power :USB 2.0 interface
5.Excellent quality: our sensor material imported from Germany and
Japan , best quality standards.
6.New APS CMOS sensor with long life time (400,000 times).
7.Warranty for 2 years
Operating conditions:
Environment Temperature : +10℃～+40℃
Environment relative humidity : ≤95%；
Air pressure : 860hPa～1060hPa；
Transport and Storage conditions:
| Environment Temperature | -25℃~+60℃ |
| Environment relative humidity | 10%~93%; |
| Air pressure | 860hPa~1060hPa |
Specification:
Sensor external dimensions 27.5x38.5mm
Sensing region 22.5*30mm
Sensor Thickness 6mm
Line Long (Material - PU) > 2m
Dynamic Range 0-4096 bits
Connection USB Standard
Display Resolution 1024*758+
Packing List:
Manual 1pcs
CD 1pcs
X-Ray Sensor and Control Box 1pcs
Holder 1pcs
Sleeves 50pcs
Safety Classifications:
Safety Type: Class-Ⅱ BF
Power: DC5V Maximum 600MA.Rate of Work: Max 1W
Degree of protection against ingress of water: IPX7
Non AP equipment, non APG equipment
Mode of operation: Continuous operation
Besides, we have some new items:X ray sensor, X ray unit and X ray
scanner
